LM393 3144 Hall Sensor Module
Audio & Music Accessories
Type
Brand New
Condition
Other
Brand
The 44E Hall Effect Sensor Module is designed to detect the presence of a magnetic field and convert it into an electrical signal. It employs a 44E Hall Effect sensor, which is a small, versatile linear Hall-effect device that is operated by the magnetic field from a permanent magnet or an electromagnet.
Specifications:
Sensor Type: 44E Hall Effect sensor
Measuring magnetic field range: min:±650, typ: ±1000
Output Signal: Digital (TTL. Max 15mA) or Analog (voltage) (depends on the supply voltage and varies in proportion to the strength of the magnetic field)
Analog output voltage span:0 to Vcc-1.0
Analog Quiescent Output Voltage:5v (at Vcc = 5.0)
Supply Voltage: Typically 3.3V to 6V DC
Sensitivity: 6mV/gauss
Operating temperature: -40„ to 85„
Fixing: A Fixing bolt hole for easy installation
Dimensions: 38x14 mm
