Main input voltage 208 v ac 1 phase
240 v ac 1 phase
other input voltages 240 v
efficiency at full load 100.275 v adjustable (half load)
number of input connectors 1 hard wire 3-wire (2ph + g)
input frequency 40 - 70 hz auto-sensing
output voltage 208 v 1 phase
240 v 1 phase
other output voltages 240 v
rated power in w 8000 w
rated power in va 8000 va
output connection type 4 nema l6-20r
2 nema l6-30r
output connector type hard wire 3-wire (2ph + g) for 1 zone(s)
bypass type internal bypass (automatic and manual)
crest factor 3 : 1
harmonic distortion less than 2%
maximum configurable power in
va
8000 va
max configurable power (watts) 8000 w
topology on-line
waveform type sine wave
output frequency 50/60 hz +/- 3 hz sync to mains
