Eaton 9e 15kva ups 9e15ki
eaton ups 9e15ki 12000watts/15000va)
topology-online double conversion
configuration-tower, in uganda
input voltage range-176-276v without derating (up to 110-276v with derating)
nominal voltage-v
frequency-50/60 hz autoselection, short circuit current -205a,
output voltage -220v/230v/240v ±2 %,
voltage thd- <3%
efficiency (normal mode)-up to 93% in online mode 97% in eco mode
overload capacity- 105%-110% : 5min, 110%-130% : 1min, 130%-150% : 10s, >150% : 100ms,
communication ports-1 usb port + 1 rs232 serial port (usb and rs232 ports cannot be used simultaneously), communication slot-1 slot for network-m2, modbus-ms or relay-ms cards,
power management software-intelligent power software
warranty - 1 year
