Working range with receiver, value
700m
Dust and splash protection
IP 68
Battery voltage
18
Laser diode
630 – 650 nm, < 1mW
Operating temperature
-10 – 50 °C
Storage temperature
-20 – 50 °C
Laser class
2
Working range with receiver
up to 600 m (Diameter)
Working range without receiver
up to 60 m (Diameter)
Accuracy
± 1.5 mm at 30 m* horizontal (*plus use-dependent deviation), ± 3.0 mm at 30 m* vertical (*plus use-dependent deviation)
Self-levelling range
±8.5% (±5°)
Rotation speed
150/300/600 min−1
Power supply
18 V Li-ion battery, 4 x D cell batteries
Operating time (max.)
60 h, 70 h
Tripod thread
2 x 5/8"
Projection
1 x 360° line
Compatible laser receivers
LR 60
Weight with 4.0 Ah battery
4.3 kg
Weight with alkaline batteries
4.6 kg
Slope function
yes
