Key technical specifications
rated power capacity: 4,200w (4.2 kw) with a surge peak capacity of 8,400va.
system battery voltage: 24v dc nominal.
solar charger (mppt) voltage range: 60v dc to 450v dc.
maximum pv array open circuit voltage (voc): 500v dc.
maximum pv input power: up to 5,000w (supports up to 6,200w on select sub-models).
maximum solar charging current: 120a.
output waveform: pure sine wave (provides clean electricity safe for sensitive electronics).
ac output voltage: 230v ac ± 5% at 50hz/60hz (auto-sensing).
