12-Core Adss 12c Fiber Optic Cable

+1

Network Cables

Type

Swift

Brand

12C ADSS

Model

Fiber Optic

Cable Type

Unshielded Cable

Cable Shielding

Other

Cable Speed

Outdoor

Usage

4000m

Cable Length

Brand New

Condition

Delivery

Across country

1-2 days

Free of charge

Store address

Kampala • Nakawa

We are located in Ntinda, Kampala Uganda (Near Total Energies Petrol Station Ntinda Kiwatule Road).

Open

• Mon, Tue, Wed, Thu, Fri, Sun, 08:00-18:00

12c adss fiber optic cable technical specificationsfiber count: 12 cores fiber type: single-mode g.652d (standard) core/cladding diameter: 9/125 μm transmission speeds: 10g / 40g / 100g+ (transceiver dependent)operating wavelengths: 1310 nm / 1550 nm attenuation: ≤ 0.36 db/km (at 1310 nm) | ≤ 0.22 db/km (at 1550 nm) construction: all-dielectric (zero metal) strength member: central frp (fiber reinforced plastic) + peripheral aramid yarns cable core design: loose tube, gel-filled outer sheath material: hdpe (high-density polyethylene) or at (anti-tracking) for high-voltage environments nominal outer diameter: 9.5 mm to 12.5 mm (varies by span rating) [1]approximate weight: 70 to 110 kg/km (varies by aramid yarn density) [1]standard span capabilities: 100m, 200m, 300m, up to 500m+ (installation specific)max allowed tensile strength (mats)
